TOPCon N-Type

TOPCon M10 module produces energy even if part of the module is shaded. Whereas if standard module is partially shaded minimum one string will completely stop producing power, this accounts to one third reduction in power generation. Moreover, it can even completely stop generating power if shaded across its breadth. TOPCON M10 series is split into two parts. Each section of 72 half-cut cells generates power on standalone basis but combines again before current exits the module. This structure results in power generation in non-shaded area of the module even if one of the section is partially or completely shaded, resulting in higher overall energy yeild as compared to standard module.

ELECTRICAL DATA@STC Module code* : SSXXX144 TOPCon N-Type
Nominal Power -P (Wp) 570 575 580 585 590 595 600
Power Tolerance -(W) 0/+5 0/+5 0/+5 0/+5 0/+5 0/+5 0/+5
Maximum Power Voltage V (V) 42.07 42.22 42.37 42.52 42.67 42.82 42.97
Maximum Power Current - I (A) 13.55 13.62 13.69 13.76 13.83 13.90 13.97
Open Circuit Voltage - Voc (V) 50.74 50.88 51.02 51.16 51.30 51.44 51.58
Short Circuit Current -I(A) 14.31 14.39 14.47 14.55 14.63 14.71 14.79
Module Efficiency - (%) 22.07 22.26 22.45 22.64 22.83 23.02 23.21

Values at standard test conditions STC (airmass AM 1.5, irradiance 1000 W/m², cell temperature 25°C)
*Where xxxx indicates the nominal power class (Pum) at STC indicated above.
