Polycrystalline solar cells are made from silicon that is melted and then poured into molds to create ingots. The ingots are then cut into wafers. These solar cells are recognizable by their blue speckled appearance.
Model Name | No. of Cells | PMAX | VMP | VOC | IMP | ISC | EFF (%) | D (mm) | W (mm) | L (mm) |
---|---|---|---|---|---|---|---|---|---|---|
INV-P-12V-20Wp | 36 | 20 | 18.36 | 22.40 | 1.09 | 1.16 | 10.64 | 30 | 345 | 545 |
INV-P-12V-30Wp | 36 | 30 | 18.36 | 22.40 | 1.63 | 1.74 | 13.28 | 30 | 345 | 655 |
INV-P-12V-40Wp | 36 | 40 | 18.36 | 22.40 | 2.18 | 2.32 | 14.15 | 30 | 665 | 425 |
INV-P-12V-50Wp | 36 | 50 | 18.36 | 22.40 | 2.72 | 2.89 | 13.67 | 30 | 665 | 550 |
INV-P-12V-60Wp | 36 | 60 | 18.36 | 22.40 | 3.27 | 3.47 | 13.57 | 30 | 665 | 665 |
INV-P-12V-80Wp | 36 | 80 | 18.36 | 22.40 | 4.36 | 4.63 | 15.52 | 30 | 665 | 775 |
INV-P-12V-100Wp | 36 | 100 | 18.61 | 22.71 | 5.37 | 5.71 | 14.89 | 30 | 665 | 1010 |
INV-P-12V-125Wp | 36 | 125 | 18.72 | 22.84 | 6.68 | 7.10 | 14.98 | 30 | 665 | 1255 |
INV-P-12V-160Wp | 36 | 160 | 18.72 | 22.84 | 8.55 | 9.09 | 16.20 | 30 | 665 | 1485 |
INV-P-12V-165Wp | 36 | 165 | 18.72 | 22.84 | 8.81 | 9.37 | 16.71 | 30 | 665 | 1485 |
